WB30X254 General Electric Coil Surface Element

Genuine OEM NEW Part WB30X254

Rating:

60 % of 100

Availability: In stock

In stock items are shipped the same day on all orders made before 4 PM Eastern Time.
Orders made after 4 PM Eastern Time, Weekend or a Holiday will ship the following business day.

Part Number:

WB30X254

Manufactured BY:

General Electric

Condition:

Genuine OEM NEW

Payment:

Safe & Secure

Dispatched From:

ApplianceParts4All

This manufacture part number # WB30X254 replaces our competitor’s part numbers: AP2027814, 23, 325507, AH244015, EA244015, PS244015, WB30X0254, WB30X5061, WB30X5094, B00MOCMRNK.

Special Price $43.99 Regular Price $48.99 (10% off)

Qty:

+ -

Payment

Does this part fit my model?

Details

This product is a 6-inch diameter surface heating element for oven/microwave combos, featuring looped terminal ends and a 1250W capacity. It is compatible with brands such as Hotpoint, General Electric, and Sears-Kenmore. Additionally, the high voltage diode serves as an essential OEM replacement part for GE microwaves. It functions as a one-way gate, allowing electrical current to flow in only one direction, which is vital for managing the electrical flow in the appliance. The diode measures about 3.5 inches in length and includes a banded side with a #8 ring terminal, and a non-banded side with a 1/4-inch female quick connect.

Unlike typical electrical components, this diode measures resistance rather than continuity. A properly functioning diode will demonstrate resistance in one direction only, indicating it is in good working order. It is suitable for use with certain models from GE, Hotpoint, and Kenmore.

This part is typically needed when there is no heat being generated.
